CLEVELAND 1 Core 16mm² BS5231, UL, CSA TRI-Rated 600/1000V Black (per meter) (1X16mm²)
TRI16BK
The cleveland cables TRI16BK is a black, 16mm² single-core Tri-Rated cable from Cleveland Cable Company, designed for internal panel wiring, switchgear, and instrumentation applications due to its high temperature and flame-retardant PVC sheathing. It meets British Standard BS6231 and also complies with UL and CSA standards, allowing for a wider operating temperature range.
Key Characteristics
- Conductor: Flexible plain annealed copper.
- Sheath: High-temperature PVC.
- Color: Black (as indicated by "BK").
- Application: Internal wiring of switchgear, control panels, metering equipment, and motor starters.
- Approvals: BS6231, UL, and CSA.
- Temperature Limits: -15°C to +105°C (UL/CSA), and -15°C to +90°C (BS6231).
Purpose
This cable is suitable for use in high-temperature environments within electrical equipment and meets the strict requirements of three major international standards, making it a reliable choice for demanding applications in panels and switchgear.
| Cable Size: 16mm² |
| Cores: 1 |
